Control 328C

8" Coaxial Ceiling Loudspeaker with HF Compression Driver

Larger Images

8" Coaxial Ceiling Loudspeaker with HF Compression Driver

Control 328C has been engineered from the ground up to deliver exceptional next-generation performance in a coaxial point source design ceiling loudspeaker.

Features

  • Consistent 120° broadband pattern control covers an extremely large area.
  • Shaped mounting baffle provides the pattern control of a 300 mm (12 in) horn from a 200 mm (8 in) driver.
  • Components
    • 200 mm (8 in) woofer with Kevlarre inforced cone and 50 mm (2 in) voice-coil.
    • 25 mm (1" exit) compression driver.
  • Extraordinary clarity for speech and vocals with extended frequency response for music.
  • 250 Watt power handling with very high sensitivity provides high SPL capability.
  • Advanced high-slope crossover network for constant coverage and smooth, natural midrange.
  • Clean, contemporary grille and optional backbox available.

Downloads

  Version Language Size Uploaded
Specifications
Control 328C/CT Spec Sheet
updated: Apr 29, 2019
    720 KB Apr 29, 2019
Manuals
Compatible Third-Party Backboxes for Control 300 Series Speakers
updated: Oct 18, 2019
    128 KB Oct 18, 2019
Ceiling Speaker Accessory Guide
updated: Oct 18, 2019
    127 KB Oct 18, 2019
Brochures
Full Line 2015 Catalog
updated: Jan 11, 2020
    11.7 MB Jan 11, 2020
Commercial Sound Full Line 2015 Catalog
updated: Oct 21, 2019
    2.02 MB Oct 21, 2019
Control 300 Brochure
updated: Apr 29, 2019
    2.9 MB Apr 29, 2019
CAD Drawings
Control 300 Ceiling Speakers
updated: Oct 18, 2019
    1.39 MB Oct 18, 2019
Bim Objects
BIM (Revit) Files
updated: Oct 03, 2019
    12.4 MB Oct 03, 2019
Compliances
JBL Control Series Passive Speakers DoC
updated: Dec 17, 2019
    179 KB Dec 17, 2019
Control 300 Series Declaration of Conformity
updated: Oct 18, 2019
    92.7 KB Oct 18, 2019
Software
Distributed System Design (DSD) v3.6.2
version 3.6.2, updated: Jan 14, 2020
3.6.2     805 KB Jan 14, 2020
Ease Data
Ease SPK/DLL Files - Full JBL Pro Line
updated: Jul 08, 2019
    20.5 MB Jul 08, 2019
Install Guides
Control 328C/CT Assembly Guide
updated: Apr 29, 2019
    539 KB Apr 29, 2019
Speaker Tunings
Commercial, CBT, and AWC Tunings 181030
updated: Feb 24, 2020
    557 KB Feb 24, 2020

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Specifications

Frequency Range (-10 dB) 45 Hz – 18 kHz
Long-Term SystemPower Rating 250 W (1000 W peak), 2 hrs150 W (600 W peak), 100 hrs
Sensitivity (2.83V@ 1m) 93 dB4 measured half-space
Frequency Response (±3 dB) 60Hz – 16 kHz
Coverage Pattern 120° conical, broadband
Directivity Factor (Q) 7.0 (Avg 1k - 16kHz)
Directivity Index (DI) 8.5dB (Avg 1k - 16kHz)
Maximum SPL 118 dB cont ave (124 dB peak)
Crossover Network 1.9 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
Nominal Impedance (321C) 8 ohms
Dimensions (H x W x D) 305 mm (12.0 in.) diameter round baffle x depth from back of baffle of 160 mm (6.3in)
