| Frequency Range (-10dB) |
80 Hz to 18 kHz |
| RESPOSTA EM FREQUÊNCIA (±3 dB) |
90 Hz to 16 kHz |
| PADRÃO DE COBERTURA |
/43: 40° x 30°/64: 60° x 40°/66: 60° x 60°/95: 90° x 50° |
| Crossover Modes |
Bi-amp / Passive switchable |
| Passive Crossover |
6th order (36 dB/oct) Linkwitz-Riley HP & LP, 850 Hz |
| Transducer Power Rating (AES) |
LF: 400 W (1600 W peak), 2 hrs. 300 W (1200 W peak), 100 hrs HF: 75 W (300 W peak), 2 hrs |
| System Power Rating |
Passive Mode: 300 W (1200 W peak), 100 hrs |
| Maximum SPL (1m) |
LF: 137 dB-SPL HF: 135 dB SPL (141 dB peak)Passive Mode: 134 dB SPL (140 dB peak) |
| System Sensitivity (1w @ 1m) |
Passive Mode: 107 dB-SPL |
| LF Driver |
M222-8A 300 mm (12 in) driver with 75 mm (3 in) voice coil |
| HF Driver |
2453H, 38 mm (1.5 in) exit compression driver with 100 mm (4 in) voice coil |
| Impedância nominal |
8 ohms |
| Enclosure |
Trapezoidal with 12.5 degree side angles, 16 mm (5/8 in) exterior |
| Suspension Attachment |
20 points (5 top, 5 bottom, 4 each side, 2 rear), M10 threaded hardware |
| Acabamento |
Black DuraFlex™ finish. White (-WH) available upon request. |
| Optional Weather Resistant Versions |
WRC for outdoor placement where the loudspeaker will be sheltered from direct exposure to the elements. |
| Grille |
Powder coated 14 gauge perforated steel, zinc-phosphate dipped, foam |
| CONEXÕES DE ENTRADA |
Neutrik Speakon® NL4, plus CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop through. |
| Environmental |
Mil-Std 810; IP-x3 per IEC529. |
| Dimensions (H x W x D in vertical orientation) |
991 x 673 x 897 mm |
| Net Weight (each) |
60.3 kg (133 lb) |
| Optional Accessories |
229-00009-01 kit of three M10 x 35 mm forged shoulder steel eyebolts. |
| Nominal LF Driver Impedance |
8 ohms |
| Nominal HF Driver Impedance |
8 ohms |
versão A,
atualizado: mai 2023
