JBL Professional ASB6125

큰 이미지

High Power Dual 15-inch Subwoofer

The ASB6125 is a high power, lightweight front-loaded vented subwoofer enclosure housing two JBL 2265H-1 Differential Drive® dual voice coil dual gap 15" woofers. These woofers feature neodymium magnets and ultra robust cones for extra long life.

특징

2 x 2265H-1 15" Differential Drive® dual voice coil dual gap, neodymium magnet transducers
1600 watts continuous pink noise, 6400 watts peak power handling capacity
Parallel/Discrete switchable input mode
Large vent area for high output with low distortion
FIR Tuning Set Matches Phase Profile to Full-Range Models
For ground-stacked or suspended applications in stand-alone arrays or in combination with other
AE Series products

To improve reliability in weather conditions and reduce water ingress, cabinet dimensions of WRC & WRX models may be different than standard model dimensions. Contact CustomAudio@harman.com for drawings and/or dimension information of WRC & WRX models.)

다운로드

Specifications

	크기	업로드 날짜
ASB6125 Spec Sheet 업데이트: 2020년 12월	369KB	2020년 12월

Manuals

	버전	언어	크기	업로드 날짜
Weather Resistant Configurations 버전 A, 업데이트: 2023년 5월	A		86.1KB	2023년 5월
AE/PD Connector Pinout Guide 업데이트: 2019년 10월			8.25KB	2019년 10월

Brochures

	크기	업로드 날짜
AE Series Brochure 업데이트: 2020년 10월	4.05MB	2020년 10월
AM Brochure 업데이트: 2020년 10월	1.54MB	2020년 10월

CAD Drawings

	버전	크기	업로드 날짜
AE Series - Revit/BIM Files 버전 11.0, 업데이트: 2024년 7월	11.0	730KB	2024년 7월
AE Series - Customer Drawings 버전 2.0, 업데이트: 2024년 5월	2.0	2.69MB	2024년 5월
AE Series - WR Models Customer Drawings 버전 3.0, 업데이트: 2026년 4월	3.0	3.8MB	2026년 4월

Compliances

	크기	업로드 날짜
AE Series ASB - Declaration of Conformity 업데이트: 2024년 7월	93.5KB	2024년 7월

Preset Libraries

	크기	업로드 날짜
AE Series DCi Series Preset Library 업데이트: 2024년 5월	471KB	2024년 5월

Application Guides

	언어	크기	업로드 날짜
Directional Bass Using 3-Element Arrays 업데이트: 2021년 8월		570KB	2021년 8월

위의 링크 중 하나에서 브라우저에 이상한 문자가 표시되면, 파일을 마우스 오른쪽 버튼으로 클릭하여 컴퓨터에 저장하세요.

부품 및 서비스

사양

Frequency Range (-10dB)	32 Hz - 1 kHz
Frequency Response (±3 dB)	38 Hz - 1 kHz
Transducer Power Rating (AES)	1600 W (6400 W peak), 2 hrs
Input Modes	Drivers Parallel / Drivers Discrete
System Power Rating	1350 W (5400 W peak), 100 hrs.
Maximum SPL (1m)	35 Hz - 400 Hz: 132 dB-SPL cont avg (138 dB peak)
System Sensitivity	35 Hz - 400 Hz: 100 dB-SPL, 1W (2.0V) @ 1m
Nominal Impedance	4 ohms in parallel-drive mode2 x 8 ohms in discrete-drive mode
LF Driver	2 x 2265H-1, 380 mm (15 in) dia., 75 mm (3 in) Dual Coil Dual Gap neodymium Differential Drive® drivers
Enclosure	Rectangular cabinet, 16 mm (5/8 in) exterior grade 11-ply birch plywood
Suspension Attachment	16 points (4 top, 4 bottom, 4 each side), M10 threaded hardware
Finish	Black DuraFlex™ finish.White available upon request.
Grille	Powder coated 14 gauge perforated steel, with acoustically transparent black foam backing.
Input Connector	NL4 Neutrik Speakon® and CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop-through.
Environmental	Mil-Std 810; IP-x3 per IEC529.
Dimensions (H x W x D in vertical orientation)	965 x 419 x 597 mm(38.0 x 16.5 x 23.5 in)
Net Weight (each)	36.7 kg (81.0 lb)
Optional Accessories	M10 x 35 mm forged shoulder eyebolts with washers
Nominal LF Driver Impedance	4 ohms in parallel-drive mode 2 x 8 ohms in discrete-drive mode
