MG1928

8-Inch Two-WayLine Array Loudspeaker System

MG1928
较大的图像

8-Inch Two-Way Line Array Loudspeaker System

The MG1928 is a lightweight compact 8" two-way line array speaker system designed for use in arrays.

特点

  • Constant Curvature Array - The waveguide mounts two compression drivers on a continuous arc enabling them to work together acoustically as if they were a single driver
  • Amplitude Shading- Convenient series of switches on each enclosures that controls the output of each high frequency section in the array
  • Differential Drive® Woofer realizes optimal acoustic performance and lightweight of the entire unit
  • Integral suspension and rigging hardware for simple installation
  • Dual Angle Pole Socket - JBL's dual angle pole sockets allow great flexibility in aiming the enclosure

下载

  Version Language Size Uploaded
Brochures
file type icon MG Series Leaflet CN
updated: 12月 2019
    1.4 MB 12月 2019

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Parts & Service

性能

系统类型 8-inch, 2-Way
Coverage 100° × 15° (H×V)
频率范围 (-10dB) 70 Hz - 20 kHz
分频点 2.0 kHz
标称阻抗 Passive: 8 ΩBi-amp LF: 8 ΩBi-amp HF:16 Ω
Power Rating *1(Continuous / Program / Peak) Passive: 400W/800W/1600WBi-amp LF: 400W/800W/1600WBi-amp HF: 30W/60W/120W
Maximum SPL *2 Passive: 122 dBBi-amp LF: 122 dBBi-amp HF: 128 dB

尺寸

230 mm × 419 mm × 267 mm
重量 12.7 kg
