MG1915M

15-Inch Two-Way Stage Monitor

MG1915M
较大的图像

15-Inch Two-Way Stage Monitor

MG1915M is a compact and low-profile 2-way stage monitor with a nominal coverage of 50° x 90° and supports Bi-amplified or full-range passive operation.

特点

  • Compact and low-profile for minimal obstruction of audience sightlines
  • 50° x 90° nominal coverage
  • Bi-amplified or full-range passive operation
  • Differential Drive® woofer with neodymium magnet for high power capacity and very light weight
  • 4" (voice coil) diameter compression driver with neodymium magnet

下载

  Version Language Size Uploaded
Brochures
file type icon MG Series Leaflet CN
updated: 12月 2019
    1.4 MB 12月 2019

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Parts & Service

性能

系统类型 15-inch, 2-way, stage monitor
Coverage 50° × 90°(H×V)
频率范围 (-10dB) 60 Hz - 20 kHz
分频点 1.1 kHz
标称阻抗 8 Ω
Power Rating *1(Continuous / Program / Peak) Passive: 800W/1600W/3200W Bi-amp LF: 800W/1600W/3200W Bi-amp HF: 75W/150W/300W
Maximum SPL *2 127 dB

尺寸

629 mm × 432 mm × 324 mm (375 mm stage height)
重量 21 kg
