| Frequency Range (-10dB) |
85 Hz - 19 kHz |
| Frequency Response (±3 dB) |
108 Hz – 16.5 kHz |
| Full Range |
800 W Continuous Pink Noise (3200 W peak), 2 hrs 400 W Continuous Pink Noise (1600W peak), 100 hrs |
| Bi-amp LF |
800 W Continuous Pink Noise (3200 W peak), 2 hrs 400 W Continuous Pink Noise (1600W peak), 100 hrs |
| Bi-amp HF |
150 W Continuous Pink Noise (600 W peak), 2 hrs 50 W Continuous Pink Noise (200 W peak), 100 hrs |
| Full-Range |
80 V Rms (2 hrs), 160 V peak |
| Maximum SPL (1m) |
131 dB Cont. Ave (2 hrs), 137 dB Peak |
| Coverage Pattern (-6 dB) |
Horizontal: 65° (+15°/-10°, 1.5 kHz to 15 kHz) Vertical: Varies with array size and configuration |
| Amplifiers |
Crown DCi Family with DSP on-boardRecommended:Crown DCi 2 | 1250NCrown DCi 4 | 1250N/ND/DACrown DCi 2 | 2400NCrown DCi 4 | 2400N |
| LF Driver |
2 x 2261FF, 254 mm (10 in) diameter, each with two 76 mm (3 in) diameter voice coils, Neodymium Differential Drive®, Direct Cooled™ |
| HF Driver |
3 x 2415K, D2 Dual Diaphragm Dual Voice Coil Compression Drivers, each with two 38 mm (1.5 in) dia. Voice Coils; 21 mm (0.8 in) exit |
| Enclosure Material |
Fiberglass shell, gelcoat finish, with 18 mm Birch plywood internal bracing. |
| Grille |
Powder coated 14 gauge hex-perforated steel with zinc under-coating, backed with acoustically transparent cloth and hydrophobic screen. |
| Inter-Enclosure Angles |
VLA-C265 to VLA-C265: 1.5°, 2.4° 3.8°, 6.0°, 9.5° using VLA-C265 Bracket Plate (included with VLA-C265)VLA-C265 to VLA-C2100 (either model on top/bottom): 1.9°, 3.0° using VLA-C2100 Bracket Plate (included with VLA-C2100) and 4.7°, 7.5°, 11.9° using VLA-C265 Bracket Plate (included with VLA-C265)VLA-C265 below VLA-C125S Subwoofer (VLA-C265 cannot be connected above C125S): 0°, 5° using VLA-C125S Bracket Plate (included with VLA-C125S) |
| Environmental |
IP-55 rating per IEC529 (dust protected and protected against jets of water). |
| Terminals |
CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9mm (0.375 in) spade lugs. Touch-proof covers. |
| Colors |
-GR: Gray (similar to Pantone 420C), -BK: Black |
| Dimensions (H x W x D) |
381 x 848 x 460 mm (15.0 x 33.4 x 18.1 in) |
| Net Weight (each) |
37.7 kg (83 lbs) |
| Shipping Weight (ea) |
44.0 kg (97 lbs) |
| Included Accessories |
2 pcs. VLA-C265 Bracket Plates
8 pcs. M10 x 35 mm stainless steel bolts (1.5mm pitch, 6 mm hex-drive) for attaching Bracket Plates
2 pcs. Plastic Trim Cover Panels for Bracket Plates, each attaches via
4 pcs (8 total) 3-32 x ½” trusshead, phillips-drive, stainless steel bolts. |
| Optional Accessories |
VLA-C-SB2 (JBL-VLACSB2BK) Suspension Bracket Kit |
