MRX618S (停产)

18" High-Power Subwoofer


18" High-Power Subwoofer

The MRX618S is a compact, high power subwoofer system containing a 2044G 457 mm (18 in) woofer in a front-loaded, vented enclosure. The enclosure is designed to present a minimum frontal area.


  • 18 inch, 2044G driver for extended low-frequency output
  • Large vent area for reduced distortion
  • Low profile and compact
  • Tough DuraFlex™ finish enclosure
  • Live performance venues
  • Mobile and fixed DJ systems


  Version Language Size Uploaded
file type icon MRX Family
updated: 10月 2019
    392.3 KB 10月 2019

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Parts & Service


频率范围 (-10dB) 40 Hz - 200 Hz
Frequency Response (±3 dB) 45 Hz - 200 Hz
Input Connection Modes Internally configurable, +1/-1 or +2/-2
Recommended Crossover 80 Hz, 24 - 48 dB/octave
Power Rating (Continuous/Program/Peak) 500 W/ 1000 W/ 2000 W, 2 hrs 400 W/ 800 W/ 1600 W, 100 hrs
Maximum SPL (1m) 127 dB SPL continuous (133 dB SPL peak)
System Sensitivity (1w @ 1m) 94 dB SPL; 100 dB SPL
低频驱动单元 1 x JBL 2044G 457 mm (18 in) woofers
标称阻抗 4 ohms
装配 Top mounted 35 mm socket for optional SS3-BK pole
Enclosure Rectangular, 18 mm, plywood
外观颜色 Black DuraFlex™ finish
网罩 Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing
输入接口 Neutrik® Speakon® NL-4 (x2)
尺寸(高 x 宽 x 厚) 560 mm x 535 mm x 700 mm (22 in x 21.0 in x 27.5 in)
净重量 32.5 kg (72 lbs)
Optional Accessories SS3-BK: Satellite speaker pole
