15SWS800

15" Subwoofer

15SWS800
较大的图像

15SWS800

Recommended for use as a subwoofer in a bass reflex or horn loaded cabinets. Capabilities: High power handling, Large linear excursion. Bandpass extension into the very low frequency zone. High power output with low distortion.

下载

  Version Language Size Uploaded
Data Sheets
file type icon 15SWS800 Spec Sheet
updated: 10月03日
    403.7 KB 10月03日
Brochures
file type icon Components Full Line 2015 Catalog
updated: 8月20日
    1.3 MB 8月20日

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Parts & Service

性能

Diameter 15"
Impedance (ohms) 8
RMS (W) 800
Musical Program (W) 1,600
SPL 1W @ 1m (dB) 93
频率范围 (-10dB) 35 to 1,500
Resonance (Hz) 37
Voice coil diameter in. (mm) 4(100)
Voice coil 4 Layer Cu
Magnet weight oz. (g) 120 (3,400)
Basket Die cast aluminum with epoxy finish
