| Frequency Range (-10dB) |
41 Hz to 1 kHz |
| Frequency Response (±3 dB) |
49 Hz to 300 Hz |
| Transducer Power Rating (AES) |
1600W (6400 W peak) 2 hrs |
| System Power Rating |
P1200 W (4800 W peak), 100 hrs |
| Maximum SPL (1m) |
128 dB-SPL cont avg (134 peak) |
| Input Modes |
Drivers Parallel / Drivers Discrete |
| Nominal Impedance |
4 ohms in parallel-drive mode |
| Sensitivity |
116 dB-SPL |
| LF Driver |
2 x JBL 2206H 300 mm (12 in) VGC drivers with 100 mm (4 in) voice coil with minimal power compression and low distortion |
| Enclosure |
Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply |
| Waveguides |
MF: PT-N64MF 600 x 600 mm (24 x 24 in) HF: PT-H64HF 300 x 300 mm (12 x 12 in) |
| Suspension Attachment |
20 points (5 top, 5 bottom, 4 each side, 2 rear), M10 threaded hardware (eyebolts NOT included, see optional accessories). |
| Finish |
Black DuraFlex™ finish. White (-WH) available upon request. |
| Optional Weather Resistant Versions |
WRC for outdoor placement where the loudspeaker will be sheltered from direct exposure to the elements. WRX for direct exposure or extreme environments. |
| Grille |
Powder coated 14 gauge perforated steel, zinc-phosphate dipped, foam backing (grille cloth backing on white units) |
| Input Connectors |
Neutrik Speakon® NL4, plus CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop through. |
| Environmental |
Mil-Std 810; IP-x3 per IEC529. For higher environmental ratings, use WRC or WRX. |
| Dimensions (H x W x D in vertical orientation) |
357 x 673 x 706 mm (14.1 x 26.5 x 27.8 in) |
| Net Weight (each) |
36.4 kg (80 lb) |
| Optional Accessories |
229-00009-01 kit of three M10 x 35 mm forged shoulder steel eyebolts. |
| Nominal LF Driver Impedance |
4 ohms in parallel-drive mode
2 x 8 ohms in discrete drive mode |
