JBL Professional SCS 8

Größere Bilder

Räumlich positionierter Surround-Lautsprecher 2-Wege-Koaxial mit 8" Tieftöner

Der SCS 8 ist ein koaxialer 2-Wege-Vollbereichs-Kinolautsprecher, ideal für mehrkanalige Surroundformate, und wurde sowohl für die Deckenmontage als auch für die Standardwandmontage entwickelt

Eigenschaften

250 Watt power handling (average continuous pink noise) with high sensitivity provides high SPL capability.
Consistent 120° x 120° broadband pattern control
Extraordinary clarity cinema surround with extended frequency response for special effects
Components:
• 200 mm (8 in) woofer with Kevlar-reinforced cone and 50 mm (2 in)
voice coil.
• 25 mm (1 in) exit compression driver with unique patented design
and high temperature polymer diaphragm.
70 Hz – 20 kHz frequency response
High-power passive crossover network
Overload protection

Downloads

Specifications

	Größe	Hochgeladen
SCS 8 Spec Sheet aktualisiert: Okt 2020	672 KB	Okt 2020

Compliances

	Größe	Hochgeladen
SCS Series Declaration of Conformity aktualisiert: Okt 2020	131 KB	Okt 2020

Falls einer der obigen Links zu seltsamen Zeichen in Ihrem Browser führt, klicken Sie bitte mit der rechten Maustaste auf die Datei, um sie auf Ihrem Computer zu speichern.

Teile & Service

Spezifikationen

Frequency Range (±3 dB)	90 Hz – 20 kHz
Frequency Range (-10dB)	70 Hz – 20 kHz
Coverage Pattern	120° x 120°
Directivity Factor (Q)	8.1 (1 k – 16 kHz)
Directivity Index (DI)	8.4 dB (1 k – 16 kHz)
Power Rating	250 W 2 hrs.200 W 100 hrs
Sensitivity	94 dB (Ave. 90 Hz – 20 kHz)
Maximum SPL (1m)	118dB
Crossover Network	2.1 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
Nominal Impedance	8Ω
LF Driver	Kevlar-reinforced cone with weather treatment, 50 mm (2 in) voice coil.
HF Driver	25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, patented design, fluidcooling.
HF Driver Protection	Minimum audibility SonicGuard™ HF overload protection
Enclosure	ABS with Glass enclosure, heavily braced
Attachment	Two M10 points for included U-bracket. M6 secondary safety attachment point on back panel.
Grille	Corrosion-resistant zinc-rich steel grille.
Input Connection	CE-compliant covered barrier strip terminals. Barrier terminals accept up to 9 mm outside 4 mm inside openlug (#6, #8 or #10) plus bare wire up to 2.5 mm2 (12 AWG) wire or spade lugs.
Dimensions	300 x 300 x 305 mm (11.8 x 11.8 x 12.0 in), cabinet 359 mm (14.2 in) including bracket extending to back
Colors	Black
Net Weight (each)	8.2 kg (18 lb), 10.0 kg (22.0 lb) with U-Bracket
Shipping Weight	11.4 kg (25.0 lb)
Included Accessories	U-bracket, steel.
Horizontal Coverage Angle (-6dB)	120°
Vertical Coverage Angle (-6dB)	120°
Power Handling (2Hr AES Rating)	250 W
